Pipe Size |
Light Series |
Nom.
size |
Outside
dia. |
Sling
rod
dia. |
D dia. |
Clip
dimen.
B x T |
P |
Clip & Load Bolts |
G
Min. |
Safe
working
load
kgf |
Bolt |
Hole
dia. |
80 |
98 |
12 |
100 |
35 x 5 |
140 |
M12 |
15 |
18 |
165 |
100 |
118 |
12 |
120 |
35 x 5 |
140 |
M12 |
15 |
18 |
165 |
*150 |
170 |
16 |
172 |
35 x 5 |
225 |
M16 |
19 |
24 |
280 |
*200 |
222 |
16 |
224 |
35 x 8 |
295 |
M16 |
19 |
24 |
450 |
*250 |
274 |
16 |
278 |
35 x 8 |
350 |
M16 |
19 |
24 |
450 |
*300 |
326 |
20 |
330 |
45 x 10 |
420 |
M20 |
24 |
30 |
900 |
350 |
378 |
24 |
380 |
60 x 10 |
480 |
M24 |
28 |
36 |
900 |
400 |
429 |
24 |
435 |
60 x 15 |
555 |
M24 |
28 |
36 |
1350 |
450 |
480 |
30 |
485 |
65 x 20 |
645 |
M30 |
35 |
45 |
2250 |
500 |
532 |
30 |
535 |
65 x 20 |
695 |
M30 |
35 |
45 |
2250 |
600 |
635 |
30 |
640 |
80 x 20 |
800 |
M30 |
35 |
45 |
2700 |
Pipe Size |
Heavy Series |
Nom.
size |
Outside
dia. |
Sling
rod
dia. |
D
dia. |
Clip
dimen.
B x T |
P |
Clip & Load Bolts |
G
Min. |
Safe
working
load
kgf |
Bolt |
Hole
dia. |
80 |
98 |
16 |
100 |
35 x 8 |
165 |
M16 |
19 |
24 |
450 |
100 |
118 |
16 |
120 |
35 x 8 |
190 |
M16 |
19 |
24 |
450 |
*150 |
170 |
16 |
172 |
35 x 8 |
245 |
M16 |
19 |
24 |
450 |
*200 |
222 |
16 |
224 |
45 x 10 |
305 |
M16 |
19 |
24 |
900 |
*250 |
274 |
20 |
278 |
60 x 10 |
365 |
M20 |
24 |
30 |
1350 |
*300 |
326 |
24 |
330 |
60 x 15 |
455 |
M24 |
28 |
36 |
1800 |
350 |
378 |
30 |
380 |
60 x 15 |
520 |
M30 |
35 |
45 |
2250 |
400 |
429 |
30 |
435 |
65 x 20 |
595 |
M30 |
35 |
45 |
2700 |
450 |
480 |
36 |
485 |
80 x 20 |
655 |
M36 |
42 |
54 |
3600 |
500 |
532 |
36 |
535 |
90 x 25 |
735 |
M36 |
42 |
54 |
4500 |
600 |
635 |
42 |
640 |
110 x 25 |
850 |
M42 |
48 |
63 |
5900 |
A dimensions in millimetres
* These clips are identical with those for steel pipe of the same nominal size.
